Name: P6 P8 P10 P16 Outdoor Led Display Rgb 256*128mm 320Mm*320Mm Module
Brand: Shenzhen GCL Electronics Co., Ltd
SKU: Grock
Price: 17.00 USD
Availability: InStock

Brand Name:	GCL
Model Number:	Grock
MOQ:	Min. order: 20
Price:	5 - 29 square meters $870，≥30 square meters $850
Packaging Details:	Packing with Flight case & Wooden box & Hard paper box
Payment Terms:	T/T,D/P,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

EMC/CE/ROHS/CCC/FCC/BIS

Application:

Outdoor Fixed Installation

Color:

Full Color

Cabinet Size:

Customized

LED Type:

SMD3535

Cabinet Maintenance:

Rear Service

Protection Level:

IP65

Weight:

45kg/sqm

Pixel Pitch:

3.81mm,5mm,6.0mm,8mm,10mm

Port:

Shenzhen

Supply Ability:

5000 Square Meter/Square Meters per Month

Highlight:

P10 Outdoor Led Display

P8 Outdoor Led Display

P16 Outdoor Led Display

Product Description

New Outdoor P6 P10 P16 Display Video Pbc Rgb 256*128mm 320Mm*320Mm Module Led P8

Product Features:

High IP Degree IP65,as strongas arrock

Highly Customizable
Can be customized into various kinds of designs:curve,cube,cylinder,etc.

Various Pixel Options
Pixel pitch options:P2.5,P3,P3.81,P4,P5,P6,P8,P10.

Product parameters:

Product	P2.5	P3	P3.81	P5	P6	P8	P10
Pitch	2.5mm	3mm	3.81mm	5mm	6mm	8mm	10mm
Density(pixels/m²)	160000	111111	68798	40000	27777	15325	10000
LED Type	SMD1415	SMD1921			SMD3535
Brightness	6000nits	6000nits	5500nits	6000 nits	6500 nits	6500nits	6500nits
Scan Method	1/16	1/16	1/16	1/8	1/8	1/4	1/3
Cabinet Size	Customized
Module Size	160*160mm	192*192mm	244*122mm	160*160mm	192*192mm	256*128mm	320*160mm
Cabinet Material	Steel (Aluminum Optional)
Cabinet Weight	45kg/m²
Protection Level	IP65
Cabinet Maintenance	Rear Service
Max Power Consumption	600 w/m²	600 w/m²	720 w/m²	720 w/m²	720 w/m²	720 w/m²	720 w/m²
Average Power Consumption	200 w/m²	200 w/m²	240 w/m²	240 w/m²	240 w/m²	240 w/m²	240 w/m²
Refresh Rate(Hz)	1920-3840HZ
Grey Scale	16 bit
Viewing Angle	H160°,V140°					H120°,V120°
Voltage	AC100~240V(50-63Hz)
Working Temperature	-30℃-+65℃
Working Humidity	10%-90%RH
Color Temperature	6500-9500K
Certifications	EMC/CE/ROHS/CCC/FCC/ISO
