P3.91 P10.4mm Outdoor Mesh LED Didsplay Screen For Rental / Concert Launch Event
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | gcl |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gflow |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Packing with Flight case & Wooden box & Hard paper box |
| Delivery Time: | 15-20Days |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Color: | Full Color |
|---|---|---|---|
| Panel Size: | 500*1000mm;500*500mm | Warranty: | 3 Years |
| Pixel Pitch: | P3.91\P10.4 | Port: | Shenzhen |
| Color: | Black | Brand Name: | GCL |
| Cabinet Weight: | 6kg | ||
| Highlight: | Outdoor Mesh LED Didsplay Screen,P10.4mm LED Didsplay Screen,P3.91 LED Didsplay Screen |
||
Product Description
P3.91 P10.4mm Outdoor Mesh LED Didsplay Screen For Rental Or Concert Launch Event
Products Description
High transparency:
With a translucency of up to 50%, it boasts excellent self-cooling properties, eliminating the need for air conditioning.
Two types of boxes can be assembled together:
The 500x1000mm and 500x500mm boxes can be mixed and matched flexibly, making them suitable for various installation spaces and helping to reduce stock costs.
Lightweight Design:
The enclosure is made from die-cast aluminum, measuring only 75mm in thickness and weighing 18KG/㎡, eliminating structural stress; a single person can easily install and maintain it.
The IP65 waterproof design:
The enclosure has a protection rating of IP65, making it suitable for use in various harsh weather conditions.
High Refresh Rate and Brightness:
The display offers smooth playback without stuttering or flickering, delivering excellent inner visual effects and vibrant, rich colors. The Gmesh-R series ensures that every frame of high frame rate video sources is clear and colorful. In contrast, ordinary screens with high frame rate video sources may result in blurriness and lag.
Parameters of Gmesh Series:
| Product | P3.9 | P10.4 |
| Pitch | 3.9-7.8mm | 10.4-10.4mm |
| Density(pixels/m²) | 32768 | 9216 |
| LED Type | SMD1921 | SMD2727 |
| Brightness | 5000nits | 5000nits |
| Scan Method | 1/8 | 1/2 |
| Panel Size | 500×500×75mm/500×1000×75mm | |
| Module Size | 500×125×12mm | |
| Panel Material | Die-casting Aluminum | |
| Panel Weight | 6kg/9kg | 5.5kg/8.5kg |
| Protection Level | IP65 | |
| Maintenance | Rear Service | |
| Max Power Consumption | 680W/sq.m | |
| Average Power Consumption | 220W/sq.m | |
| Refresh Rate | 3840Hz | |
| Grey Scale | 16bit | |
| Viewing Angle | H140°,V140° | |
| Voltage | AC100~240V(50-60Hz) | |
| Working Temperature | -30℃ to 60℃ | |
| Working Humidity | 10%-90%RH | |
| Color Temperature | 3000-9500K | |
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO | |
FAQ:
Q1. Is GCL a manufacturer or a trading company? Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty? The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms? Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time? Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer? We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q6: What controlling system do you use ? Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order? Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED diod, IC, module mask, power supply, receiving card, etc.
