Grock P6/P8/P10 Outdoor LED Display Billboard High Resolution Water Proof and IP65 Protection Level

Brand Name:	GCL
Model Number:	Gsurface II
MOQ:	Min. order: 20
Price:	Negotiable
Packaging Details:	Packing with Flight case & Wooden box & Hard paper box

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

EMC/CE/ROHS/CCC/FCC/BIS

Application:

OUTDOOR

Type:

LED

Color:

FULL COLOR

Panel Size:

320*320mm

Usage:

Outdoor Waterproof

Display Function:

Animation

Brightness:

6000nits

Protection Level:

IP65

Viewing Angle:

140/140 Degree

Refresh Rate:

1920Hz-3840Hz

LED Chip:

Nationstar

Cabinet Material:

Iron

Control System:

Novastar

Warranty:

3 Years

Pixel Pitch:

P4 P5 P6 P8 P10

Port:

Shenzhen

Supply Ability:

5000 Square Meter/Square Meters per Month

Highlight:

High Resolution Outdoor LED Display Billboard

Water Proof Outdoor LED Display Billboard

Product Description

Grock P6 P8 P10 Outdoor Led Display Billboard High resolution Water Proof Led screen Panel outdoor

Easy Front Maintenance
Only need to loose two module locks to remove a module

Seamless L Shape Design

Great Gray Scale
Most LED screens from other suppliers have a low gray scale, so some of the colors can't be displayed on the screen, and the image on the LED screen appears like a ghost image. Our LED screen grays cale is 13bits ~ 16bits. It is very high so the image looks very vivid and perfect.

·100%full front maintenance

·Independently waterproof modules

·Mount on the wall directly,without any steel structure

·High-end profile aluminum cabinet,anti-rust

·90°angle design available

Parameters of Grok Series:

Product	10	8	5.95
Pixel Pitch (mm)	10	8	5.95
Pixel Density (dot/㎡)	10000	15625	28476
LED Type	SMD3535	SMD3535	SMD2727
Scanning	3S	5S	9S
Module Size (mm)	320*320	320*320	320*320
Cabinet Size (mm)	Customized
Cabinet Weight (±0.25Kg)	40kg/㎡
Cabinet Resolution (PX* PX)	Customized
Cabinet Material	Steel (or Aluminum)
Brightness (CD/㎡)	6500
Maximum Power Consumption (w/sqm)	720
Average Power Consumption (w/sqm)	240
Horizontal Viewing Angle (Deg)	140°
Vertical Viewing Angle (Deg)	140°
Grey Scale(bit)	16
Refresh Rate (Hz)	1920-3840Hz
Input Voltage (V)	110-240V
Input Frequency (Hz)	60
Storage Temperature (℃)	﹣40℃－﹢80℃
Working Temperature(℃)	﹣20℃－﹢65℃
Working Humidity (RH)	95%
Cabinet Curve	Outward&Inward
Waterproof Level	IP65
Working Environment	Outdoor
Installation Type	Fixed installation

Grock P6/P8/P10 Outdoor LED Display Billboard High Resolution Water Proof and IP65 Protection Level 0

Grock P6/P8/P10 Outdoor LED Display Billboard High Resolution Water Proof and IP65 Protection Level 1

Grock P6/P8/P10 Outdoor LED Display Billboard High Resolution Water Proof and IP65 Protection Level 5
