Waterproof GCL P3 Digital LED Poster For Indoor And Outdoor 3mm Pixel Pitch Display
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gposter B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | To protect the LED screen well during the long transportation :<br>1) If it's for rental use, we will pack all cabinets by flight cases;<br>2) If it's for fixed installation, we will pack all cabinets by plywood cases. |
| Supply Ability: | 10000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Indoor, Outdoor, Video Play | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | H75.6"xW37.8"(Customized), H75.6"xW37.8"(Customized) |
| Supplier Type: | Original Manufacturer, ODM, OEM | Media Available: | Photo, Other, Video |
| Use: | Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Airport, Subway, Restaurant & Hotel Supplies, Medical Treatment, Street Lamp, Bus Station | Pixel Pitch: | 3mm, 3mm |
| Specification: | Digital Poster | Touch Screen Type: | Capacitive |
| Brightness: | 4500nits, 4500nits, 4500nits | Contrast Ratio: | 5000:1, 5000:1 |
| Color Depth: | 256, 256 | Lifespan (hours): | 100,000, 100,000 |
| IP Rating: | IP65, IP65 | Resolution: | 2K-4K |
| View Angle（H/V）: | H160°/V140°, H160°/V140° | Total Poster Size: | H82.7"xW44.9"xT8.3"(Customizable) |
| Warranty: | 3years | Usage: | Advertising LED Display |
| Refresh Rate: | 3840HZ | Weight: | 70kg/pcs |
| Installation: | Fixed | Cabinet Material: | Tempered Glass+Galvanlized Aluminim |
| IP Rate: | IP65 | Input Voltage: | AC100~240V (50 -63 HZ) |
| Port: | ShenZhen | ||
| Highlight: | Waterproof Digital LED Poster,3mm Pixel Pitch Digital LED Poster,3mm Pixel Pitch LED Poster Screen |
||
Product Description
Waterproof GCL P3 LED Video Wall Panel for Indoor and Outdoor Display 3mm Pixel Pitch
Products Description:
Artificial Intelligence Signage Low Price Outdoor Lcd Led Display Electronic Waterproof Advertising Screen
1. Screen size: 55/65/70/75/86 inch (optional)
2. Operating system: Stand alone / Android / windows (optional)
Support remote and local program management (optional)
3. Anti corrosion: more than 5years.
Waterproof / dustproof: IP55 / IP65.
Anti theft: the base adopts internal lock design
High light transmittance of glass
The whole machine adopts modular design, which is convenient for installation and maintenance.
4. Brightness:
Brightness up to 1000-3000nit, visible under strong light
Screen resolution: 2K ~ 4K.
The visual angle is 178 °.
5. Intelligent temperature control system
Air cooling
Automatic temperature system
Professional and special heat dissipation design
Parameters of Gposter-B Series:
| Name | P1.875 | P2 | P2.5 | P3 | P4 |
| Module | |||||
| LED Type | SMD1515 | SMD1515 | SMD1921 | SMD1921 | SMD1921 |
| Pixel Pitch(mm) | 1.875 | 2 | 2.5 | 3 | 4 |
| Density(pixels/m) | 512*1024 | 480*960 | 384*768 | 320*640 | 240*480 |
| Module Size (mm) | 240*240 | 240*240 | 320*160 | 320*160 | 320*160 |
| Cabinet | |||||
| Module Quantity | 4*8 | 4*8 | 3*12 | 3*12 | 3*12 |
| LED Screen Size(mm) | 960*1920 Customizable | ||||
| Cabinet Size(mm) | 1140*2100*210 | ||||
| Cabinet Area(㎡) | 2.394 | ||||
| Cabinet Material | Tempered Glass +Galvanized Aluminum | ||||
| Cabinet Weight | 70kg | ||||
| Control Method | 4G/Wireless Network/Ethernet+Cloud Cluster Control+Mobile Application | ||||
| Protection Leve | IP65 | ||||
| Optics | |||||
| Brightness (nits) | 1000nits | 1000nits | 3500nits | 4500nits | 5500nits |
| Color Temperature | 6500-9500K | ||||
| Viewing Angle | H160°,V160° | H160°,V140° | |||
| Brightness Sensor | 0-255 Level Automatic Adjustment (Optional) | ||||
| ContrastRatio | 4000:1 | ||||
| Grey Scale | 13-16bit | ||||
| Electric | |||||
| Max Power Consumption/m² | 1200W | 1200W | 1800W | 1800W | 1800W |
| Average Power Consumption/㎡ | 400W | 400W | 600W | 600W | 600W |
| Cabinet Maintenance | Full Front/Rear Service | ||||
| Input Voltage | AC100~240V(50-60Hz) | ||||
| Performance | |||||
| Drive Mode | Constant Current Drive | ||||
| Refresh Rate | 2880-3840Hz | ||||
| Optional Component | |||||
| Power Control | Remote Power Control(Optional) | ||||
| Monitoring System | HD Camera(Optional) | ||||
| Sound System | Power Consumption 10-30W(Optional) | ||||
| Environmental Test | Temperature/Humidity/PM2.5(Optional) | ||||
| Chassis Wheels | H27.5mm,Removable(Optional) | ||||
FAQ
Q1. Is GCL a manufacturer or a trading company?
Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty?
The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms?
Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time?
Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer?
We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q6: What controlling system do you use ?
Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order?
Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty?
The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms?
Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time?
Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer?
We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q6: What controlling system do you use ?
Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order?
Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED diod, IC, module mask, power supply, receiving card, etc.
