4G Wifi Control P3 LED Poster Display Floor Standing Advertising Billboard
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Poster B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | plywood,flight case,paper board |
| Supply Ability: | 2000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Indoor | Color: | Full Color |
|---|---|---|---|
| Panel Size: | W1140*H2100*T210mm | Brightness: | 3500nits |
| Bottom Wheel: | H27.5mm | Resolution: | 320*640 |
| Warranty: | 3 Years | LED Type: | SMD1921 (3in1) |
| Module Size: | 320*160mm | Usage: | Advertising |
| Led Size: | W960*H1920mm | Cabinet Size: | Tempered Glass+Galvanized Aluminum |
| Refresh Rate: | 2880hz~3840hz | Pixel Pitch: | 3.07 |
| Port: | Yantian(Shenzhen) Shekou(Shenzhen) | ||
| Highlight: | 4G Wifi Control LED Poster Display,Floor Standing LED Poster Display,Floor Standing Digital LED Poster |
||
Product Description
4G Wifi Control for W960*H1920mm P3 LED Screen on Floor Standing Advertising Billboard
Slim & Lightweight Design
GCL Poster Screen is lightweight, and the cabinet frame and LED parts are reliable and portable. Frameless design makes the product easy to move and be suitable for narrow space.
Unique Base-Standing Bracket
The base-standing bracket can make the LED poster stand on the ground stably. The bracket is movable with 4 wheels, which makes the poster can rotate freely and allow free movement in all directions.
Excellent Visual Display
GCL Poster Screens are equipped with high-quality LEDs and Driving IC to ensure high refresh rate and high contrast ratio.The Refresh rate is up to 2880Hz and high definition image quality with 5000:1. The brightness reaches to 1000 Nits that provide the viewers with perfect display effect.
Seamless Splicing
GCL Poster Screen is designed with quick connectors, and can be connected with other screens to form a large one seamlessly to play as one big screen, offering seamless display performance for better visual effect.
Seamless Splicing
GCL Poster Screen is designed with quick connectors, and can be connected with other screens to form a large one seamlessly to play as one big screen, offering seamless display performance for better visual effect.
Application Place:
Theaters , shopping malls , airports , fashion shops , metro stations , hotel reception halls , wedding posters, 4S car shops etc.
Parameters of Gposter-B Series:
| Name | P1.875 | P2 | P2.5 | P3 | P4 |
| Module | |||||
| LED Type | SMD1515 | SMD1515 | SMD1921 | SMD1921 | SMD1921 |
| Pixel Pitch(mm) | 1.875 | 2 | 2.5 | 3 | 4 |
| Density(pixels/m) | 512*1024 | 480*960 | 384*768 | 320*640 | 240*480 |
| Module Size (mm) | 240*240 | 240*240 | 320*160 | 320*160 | 320*160 |
| Cabinet | |||||
| Module Quantity | 4*8 | 4*8 | 3*12 | 3*12 | 3*12 |
| LED Screen Size(mm) | 960*1920 Customizable | ||||
| Cabinet Size(mm) | 1140*2100*210 | ||||
| Cabinet Area(㎡) | 2.394 | ||||
| Cabinet Material | Tempered Glass +Galvanized Aluminum | ||||
| Cabinet Weight | 70kg | ||||
| Control Method | 4G/Wireless Network/Ethernet+Cloud Cluster Control+Mobile Application | ||||
| Protection Leve | IP65 | ||||
| Optics | |||||
| Brightness (nits) | 1000nits | 1000nits | 3500nits | 4500nits | 5500nits |
| Color Temperature | 6500-9500K | ||||
| Viewing Angle | H160°,V160° | H160°,V140° | |||
| Brightness Sensor | 0-255 Level Automatic Adjustment (Optional) | ||||
| ContrastRatio | 4000:1 | ||||
| Grey Scale | 13-16bit | ||||
| Electric | |||||
| Max Power Consumption/m² | 1200W | 1200W | 1800W | 1800W | 1800W |
| Average Power Consumption/㎡ | 400W | 400W | 600W | 600W | 600W |
| Cabinet Maintenance | Full Front/Rear Service | ||||
| Input Voltage | AC100~240V(50-60Hz) | ||||
| Performance | |||||
| Drive Mode | Constant Current Drive | ||||
| Refresh Rate | 2880-3840Hz | ||||
| Optional Component | |||||
| Power Control | Remote Power Control(Optional) | ||||
| Monitoring System | HD Camera(Optional) | ||||
| Sound System | Power Consumption 10-30W(Optional) | ||||
| Environmental Test | Temperature/Humidity/PM2.5(Optional) | ||||
| Chassis Wheels | H27.5mm,Removable(Optional) | ||||
