Waterproof 3D Naked Eye Outdoor LED Display LED Digital Signage Display For Retail Store
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gsurface IV |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
|
Detail Information |
|||
| Application: | Outdoor | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 960*960mm |
| Supplier Type: | Original Manufacturer, ODM, OEM | Media Available: | Photo, Other |
| Use: | Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment | Pixel Pitch: | 10mm, 10mm |
| Specification: | Digital Poster, Video Wall | Touch Screen Type: | Capacitive |
| Brightness: | 6000-10000nits | Pixel Density: | 10000 |
| Contrast Ratio: | 9000:1 | Color Depth: | 256 |
| Lifespan (hours): | 100,000 | IP Rating: | IP65 |
| HS Code: | 8528591090 | Resolution: | 3840Hz |
| View Angle（H/V）: | H120°,V120° | Module Size: | 480*320mm |
| Cabinet Material: | 960*960mm | LED Type: | DIP 346 |
| After-sales Service Provided: | 3 Years | Scan Method: | 1/4s |
| Cabinet Weight: | 25KG | Maintenance: | Front & Rear Service |
| Grey Scale: | 13-16 Bit | ||
| Highlight: | Retail Store Outdoor LED Display,Waterproof Outdoor LED Display,Retail Store Outdoor LED Display Board |
||
Product Description
| Name |
P4 |
P5.71 |
P6.67 |
P8 |
P10 |
P10D |
P16 |
|
Module |
|||||||
|
LED Type |
SMD1921 |
SMD2727 |
SMD2727 |
SMD2727 |
SMD2727 |
DIP346 |
DIP346 |
|
Pixel Pitch(mm) |
4 |
5.71 |
6.67 |
8 |
10 |
10 |
16 |
|
Module Resolution |
120*80 |
84*56 |
72*48 |
60*40 |
48*32 |
48*32 |
30*20 |
|
Module Size(mm) |
480*320*20 |
480*320*20 |
480*320*20 |
480*320*20 |
480*320*20 |
480*320*30 |
480*320*30 |
|
Scan Method |
1/8s |
1/7s |
1/6s |
1/4s |
1/2s |
1/4s |
Static |
|
Cabinet |
|||||||
|
UnitResolution |
2*3 |
2*3 |
2*3 |
2*3 |
2*3 |
2*3 |
2*3 |
|
Cabinet Resolution |
240*240 |
168*168 |
144*144 |
120*120 |
96*96 |
96*96 |
60*60 |
|
Cabinet Size(mm) |
960*960*78;Customizable |
960*960*83;Customizable |
|||||
|
Cabinet Area(㎡) |
0.9216 |
||||||
|
Cabinet Material |
Profile Aluminum |
||||||
|
Cabinet Weight |
30kg |
30kg |
29.54kg |
29.48kg |
29.42kg |
38.84kg |
38.84kg |
|
Density (pixels/m²) |
62500 |
30626 |
22502 |
15625 |
10000 |
10000 |
3096 |
|
Protection Level |
IP65 |
||||||
|
Optics |
|||||||
|
Brightness(nits/㎡) |
6000 |
6500 |
6500 |
6500 |
6500 |
10000 |
10000 |
|
Calibration |
Support Single-dot Calibration |
||||||
|
Color Temperature |
1700-9500K Adjustable |
||||||
|
Viewing Angle |
H120°,V120° |
H100,V50° |
|||||
|
Light Decay Rate |
<3% |
||||||
|
Contrast Ratio |
≥9000:1 |
||||||
|
Grey Scale |
13-16bit |
||||||
|
Electric |
|||||||
|
Max Power Consumption/m² |
500W |
500W |
500W |
500W |
500W |
330W |
280W |
|
Average Power Consumption/m² |
150W |
150W |
150W |
150W |
150W |
120W |
90W |
|
Cabinet Maintenance |
Full Front/Rear Service |
||||||
|
Input Voltage |
AC100~240V(50-60Hz) |
||||||
|
Performance |
|||||||
|
Drive Mode |
Constant Current Drive |
||||||
|
Refresh Rate |
≥3840Hz |
||||||
|
FrameRate |
60Hz |
||||||
