SMD P8 P10mm Outdoor Fixed LED Display With Front Rear Service Waterproof Advertising Led Display Screen

Brand Name: GCL
Model Number: GA
MOQ: Min. order: 20
Price: Negotiable
Packaging Details: Single package size:101X116X13 cm
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
EMC/CE/ROHS/CCC/FCC/BIS
Application:
Outdoor
Type:
LED
Panel Size:
960*960 Mm
Use:
Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Airport, Subway, Elevator, Restaurant & Hotel Supplies, Education, Medical Treatment
Function:
SDK
Pixel Pitch:
8mm, 10mm
Specification:
Digital Poster, Video Wall
Touch Screen Type:
Capacitive
Brightness:
6000-10000nits
Pixel Density:
15625
Contrast Ratio:
9000:1
Color Depth:
256
Lifespan (hours):
100000
Resolution:
3840Hz
View Angle（H/V）:
H120°,V120°
Module Size:
480*320mm
Cabinet Material:
Alumium
LED Type:
SMD2727
After-sales Service Provided:
3 Years
Scan Method:
1/5
Cabinet Weight:
29.48KG
Maintenance:
Front & Rear Service
Grey Scale:
13-16 Bit
Supply Ability:
2000 Square Meter/Square Meters per Month
Highlight:

GCL P8 Outdoor Fixed LED Display

,

Touch Screen Outdoor Fixed LED Display

,

Touch Screen Outdoor LED Display

Product Description

GCL P8 ,P10 Outdoor Led Display Panels with Front Rear Service and Capacitive Touch Screen


High Brightness
High-quality LEDs can reach 10,000 nits. The pixel pitch are  P5.71, P6.67, P8, P10(DIP);

High Resolution
Fine pixel pitches form high resolution, which can capture and hold the attention of passerby.

Visual Performance
High contrast: The contrast ratio of the LED screen gives a sharp image quality.
High brightness: The brightness of the LED Display can be up to 10,000 nits. Even the screen is facing directly sunlight, the image still looks clear.

Energy Saving
We use customized PCB and power supply, so average power consumption is less than 150W/sqm.
Compared with the similar products in the market. Our GA Series LED display saves 20% energy.

Ultra-Wide Viewing Angle
With a 160 degree wide viewing angle, the screen can be seen from as various positions as possible.

Technical Features
1. Adopting dual voltage power supply technology, energy conservation and emission reduction;
2. The module box is fully enclosed with excellent waterproof performance;
3. Multiple boxes can be mixed and spliced for use;
4. Simpler and more efficient front-end maintenance
5. Seamless corner design, patented

Application compatible with scenes
Conference
Exhibition
Training
Stage Performance
Office Work
Curved Wall
Curved Design
Round Shape

Parameters of GA Series


ProductP5.71P6.67P8P10P10D
Pitch5.71mm6.67mm8mm10mm10mm
Density(pixels/m²)3062522500156251000010000
LED TypeSMD2727SMD2727SMD2727SMD2727DIP346
Brightness6500nits6500nits6500nits6500nits10000nits
Scan Method1/71/61/41/21/4
Panel Size960×960mm
Module Size480×320mm
Panel MaterialProfile Aluminum
Panel Weight30kg29.5kg29.5kg29.5kg38.8kg
Protection LevelIP65
MaintenanceFront&Rear Service
Max Power Consumption650W/㎡650W/㎡650W/㎡650W/㎡350W/㎡
Average Power Consumption210W/㎡210W/㎡210W/㎡210W/㎡110W/㎡
Refresh Rate3840Hz
Grey Scale13-16bit
Viewing AngleH140°,V120°H140°,V120°H140°,V120°H140°,V120°H100°,V50°
VoltageAC96~264V(50-60Hz)
Working Temperature-30℃ to 60℃
Working Humidity10%-90%RH
Color Temperature3000-9500K
CertificationsCE/ROHS/EMC/TUV/UL/CCC/FCC/ISO

SMD P8 P10mm Outdoor Fixed LED Display With Front Rear Service Waterproof Advertising Led Display Screen 0SMD P8 P10mm Outdoor Fixed LED Display With Front Rear Service Waterproof Advertising Led Display Screen 1
SMD P8 P10mm Outdoor Fixed LED Display With Front Rear Service Waterproof Advertising Led Display Screen 2SMD P8 P10mm Outdoor Fixed LED Display With Front Rear Service Waterproof Advertising Led Display Screen 3
