High Brightness Media Facade LED Screen Waterproof Led Video Wall With Nationstar Chip
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Grock |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | Packing with Flight case & Wooden box & Hard paper box |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 960*960, 960*960 |
| Supplier Type: | Original Manufacturer, ODM, OEM | Media Available: | Photo |
| Use: | Advertising Publish, Shopping Mall, Self-service Business, Restaurant & Hotel Supplies | Pixel Pitch: | 10mm, 10mm |
| Specification: | Digital Poster, Touch Screen, Video Wall | Touch Screen Type: | Capacitive, Touchscreen |
| Brightness: | 8000nits, 8000nits, 6500nits | Pixel Density: | 10000, 10000 |
| Contrast Ratio: | 5000:1, 5000:1 | Lifespan (hours): | 10,0000, 10,0000 |
| IP Rating: | 65, 65 | Resolution: | 2K~4K |
| LED Chip: | Nationstar | Cabinet Size: | 960x960mm |
| Scan Mode: | 1/3scan | Usage: | Advertising |
| Refresh Rate: | 1920Hz-3840Hz | Viewing Angle: | H120 V120 |
| Cabinet Material: | Iron | Certificate: | CE ROHS FCC |
| Input Voltage: | AC100~240V 50 /60 HZ | Port: | Shenzhen |
| Highlight: | High Brightness Media Facade LED Screen,Waterproof Media Facade LED Screen,Nationstar Chip Media Facade Lighting |
||
Product Description
High Brightness P3 P4 P5 P6 P8 P10 Waterproof Led Video Wall with Nationstar LED chip
Products Description
Product Parameter
|
Model
|
Grock10
|
Grock8
|
Grock6
|
||
|
Pixel Pitch (mm)
|
10
|
8
|
6
|
||
|
Pixel Density (dot/m2)
|
10000
|
15625
|
27777
|
||
|
LED Type
|
SMD3535
|
SMD3535
|
SMD3535
|
||
|
Scanning
|
3S
|
4S
|
8S
|
||
|
Module Size (mm)
|
320*160
|
256*128
|
192*192
|
||
|
Cabinet Size (mm)
|
Customized
|
Customized
|
Customized
|
||
|
Cabinet Weight
|
45kg/sq.m (±0.25Kg)
|
45kg/㎡
|
45kg/㎡
|
||
|
Cabinet Resolution
|
Customized
|
Customized
|
Customized
|
||
|
Cabinet Material
|
Steel (or Aluminum)
|
Steel (or Aluminum)
|
Steel (or Aluminum)
|
||
|
Brightness
|
6500 nit
|
6500
|
6000
|
||
|
Maximum Power Consumption
|
720w/sqm
|
720
|
720
|
||
|
Average Power Consumption
|
240 w/sqm
|
240
|
240
|
||
|
Horizontal Viewing Angle
|
140°
|
140°
|
140°
|
||
|
Vertical Viewing Angle
|
140°
|
140°
|
140°
|
||
|
Grey Scale
|
16bit
|
16
|
16
|
||
|
Refresh Rate
|
1920-3840Hz
|
1920-3840Hz
|
1920-3840Hz
|
||
|
Input Voltage
|
110-240V
|
110-240V
|
110-240V
|
||
|
Input Frequency
|
60Hz
|
60
|
60
|
||
|
Storage Temperature
|
﹣40℃－﹢80℃
|
﹣40℃－﹢80℃
|
﹣40℃－﹢80℃
|
||
|
Working Temperature
|
﹣20℃－﹢65℃
|
﹣20℃－﹢65℃
|
﹣20℃－﹢65℃
|
||
|
Working Humidity
|
95% RH
|
95%
|
95%
|
||
|
Cabinet Curve
|
Outward&Inward
|
Outward&Inward
|
Outward&Inward
|
||
|
Waterproof Level
|
IP65
|
IP65
|
IP65
|
||
|
Working Environment
|
Outdoor
|
Outdoor
|
Outdoor
|
||
|
Installation Type
|
Fixed installation
|
|
Fixed installation
|
||
Application
Exhibition
FAQ
Q1. Is GCL a manufacturer or a trading company?
Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty?
The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms?
Payment terms:30% T/T deposit, 70% T/T before shipment.
Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty?
The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms?
Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time?
Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer?
We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer?
We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q6: What controlling system do you use ?
Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order?
Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order?
Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable, signal cable, Led diod, IC, Module mask, power supply, receiving cards, etc.
