Quick Heat Dissipation Digital Outdoor Fixed Led Display With Multiple Installation Methods
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gpro |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | plywood,flight case,paper board |
| Supply Ability: | 2000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 960X640mm, 960X640mm |
| Supplier Type: | Original Manufacturer, ODM, OEM | Media Available: | Photo, Other, Video |
| Use: | Advertising Publish, Retail Store, Shopping Mall, Restaurant & Hotel Supplies, Large Commercial Complex, Urban Landmark, Large Sports Center | Pixel Pitch: | 10mm, 10mm |
| Specification: | Digital Poster, Video Wall | Touch Screen Type: | Capacitive |
| Brightness: | 10000nits, 10000nits, 10000nits | Pixel Density: | 10000, 10000 |
| Lifespan (hours): | 100,000, 100,000 | IP Rating: | IP 65, IP 65 |
| Resolution: | 2k-4k | View Angle（H/V）: | H120°/V120°, H120°/V120° |
| Density: | 10000 | LED Type: | SMD2727 |
| Scan Method: | 1/4 | Module Size: | 320*320mm |
| Cabinet Material: | Die-casting Aluminum | Cabinet Weight: | 18kg |
| Cabinet Service: | Front And Rear Service | Refresh Rate: | 3840HZ |
| Viewing Angle: | H120°/V120° | Port: | Shenzhen |
| Highlight: | Digital Outdoor Fixed LED Display,Multiple Installation Outdoor Fixed LED Display,Quick Heat Dissipation Outdoor LED Display |
||
Product Description
Products Description
| Product | P2.5 | P4 | P5.9 | P8 | P10 | P10D | P16 |
| Pitch | 2.5mm | 4mm | 5.92mm | 8mm | 10mm | 10mm | 16mm |
| Density(pixels/m²) | 160000 | 62500 | 28476 | 15625 | 10000 | 10000 | 3906 |
| LED Type | SMD1415 | SMD1921 | SMD2727 | SMD2727 | SMD2727 | DIP346 | DIP346 |
| Brightness | 6000nits | 6000nits | 7000nits | 7000nits | 7000nits | 8000nits | 8000nits |
| Scan Method | 1/16 | 1/10 | 1/6 | 1/4 | 1/2 | 1/4 | 静态 |
| Panel Size | 640×960mm | ||||||
| Module Size | 320×320mm | ||||||
| Panel Material | Die-casting Aluminum | ||||||
| Panel Weight | 23.5Kg | 23.5Kg | 19Kg | 19Kg | 19Kg | 21Kg | 21Kg |
| Protection Level | IP65 | ||||||
| Maintenance | Front/Rear Service | ||||||
| Max Power Consumption | 650W/㎡ | 720W/㎡ | 720W/㎡ | 720W/㎡ | 720W/㎡ | 350W/㎡ | 350W/㎡ |
| Average Power Consumption | 210W/㎡ | 240W/㎡ | 240W/㎡ | 240W/㎡ | 240W/㎡ | 110W/㎡ | 110W/㎡ |
| Refresh Rate | 3840Hz | ||||||
| Grey Scale | 13-16bit | ||||||
| Viewing Angle | H160°,V140° | H100°,V50° | |||||
| Voltage | AC100~240V(50-60Hz) | ||||||
| Working Temperature | -30℃ to 60℃ | ||||||
| Working Humidity | 10%-90%RH | ||||||
| Color Temperature | 3000-9500K | ||||||
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO | ||||||
similar to Absen's XD Plus series but with much more competitive price
ABOUT GCL
Shenzhen GCL Electronics CO., Ltd, founded in 1999, is a professional LED display manufacturer which integrates research, development, manufacturing, engineering, installing, sales and aftersales service. Headquartered in Shenzhen, China, GCL is staffed with over 300 employees and in our dust free workshop which covers more than 100,000 square feet, there are more than 40 high-speed production machines with high accuracy and more than 10 modern assembly lines. GCL has a very powerful productivity with over 5000 square meters LED screens each month. We have been granted with more than ten LED application products-related patents and certifications in compliance with the ISO 9001, ISO 1400 and ISO18001 standards. Our products have also been certificated with multiple standards, including CCC, FCC, CE, ROHS, UL, EMC, and ETL. GCL has finished more than 10,000 led screen projects all over the world, including some magnificent international government projects such as 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc. We have warehouses in America, Russia and Malaysia.
1999
GCL was registered and founded in Shenzhen, China.
2006
2011
GCL was registered and founded in Shenzhen, China.
2006
Overseas Department of GCL was founded, and GCL settled the first order overseas, 80sqm of outdoor P24 in Russia.
2007
GCL was awarded the design patent certificate of Utility Model for outdoor display listed. 2010 GCL was the LED screen supplier ofShanghai EXPO.
2011
GCL moved from Bao’an district to Longgang district for expanding the production.
2012
GCL became a member of China Optoelectronics Industry Association.
2014
GCL developed partnership cooperation in Russia, Sweden and the USA.
2015
GCL was the LED screen supplier for Milan EXPO 2015.
2016
GCL set up after-sales service center in Europe and the US.
2017
GCL set up the warehouse in Malaysia.
2018
GCL set up the warehouse and office in Texas, the US.
2019
GCL set up the warehouse and office in Moscow, Russia.
Want to Know more details about this product
