High Brightness 6500nits Outdoor LED Display Board Media GCL P6 HD LED Video Wall
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Grock |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | Packing with Flight case & Wooden box & Hard paper box |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Color: | Full Color |
|---|---|---|---|
| Panel Size: | 256*128mm | Supplier Type: | ODM, OEM |
| Media Available: | Other | Use: | Advertising Publish |
| Function: | SDK | Specification: | Digital Poster, Video Wall |
| LED Chip: | Nationstar | Cabinet Size: | Customize |
| Brightness: | 6500nits | Scan Mode: | 1/4scan |
| Usage: | Advertising | Refresh Rate: | 1920Hz-3840Hz |
| Viewing Angle: | H120 V120 | Cabinet Material: | Iron |
| Certificate: | CE ROHS FCC | Input Voltage: | AC100~240V 50 /60 HZ |
| Pixel Pitch: | 6mm, P3.91 P4 P6 P8 P10 | Port: | Shenzhen |
| Highlight: | High Brightness Outdoor LED Display Board,Media Outdoor LED Display Board,High Brightness Outdoor LED Display Screen |
||
Product Description
Product Details
| Product | P2.5 | P3 | P3.81 | P4 | P6 | P8 | P10 |
| Pitch(mm) | 2.5 | 3 | 3.81 | 4 | 6 | 8 | 10 |
| Density(pixels/m2) | 160000 | 111111 | 68798 | 62500 | 27777 | 15625 | 10000 |
| LED Type | SMD1415 | SMD1921 |
SMD3535
|
||||
| Brightness(nits) | 5000 | 5500 | 5500 | 5500 | 6500 | 6000 | 5500 |
| Cabinet Material | Customized | ||||||
| Cabinet Weight | 45kg/㎡ | ||||||
| Protection Level | IP65 | ||||||
| Cabinet Maintenance | 100% Rear Service | ||||||
| Max Power Consumption | 720w/㎡ | 720w/㎡ | 800w/㎡ | 800w/㎡ | 800w/㎡ | 800w/㎡ | 800w/㎡ |
| Average Power Consumption | 240w/㎡ | 240w/㎡ | 270w/㎡ | 270w/㎡ | 270w/㎡ |
270w/㎡
|
270w/㎡
|
| Refresh Rate | 2880-3840Hz | ||||||
| Grey Scale | 16 bit | ||||||
| Viewing Angle | H160°,V140° | ||||||
| Voltage | AC100~240V(50-63Hz) | ||||||
| Working Temperature | ‘-30 ℃- + 65 ℃ | ||||||
| Working Humidity | 10% -- 90%RH | ||||||
| Color Temperature | 6500-9500K | ||||||
| Certificationa | EMC/CE/ROHS/CCC/FCC/ISO | ||||||
Why Choose Us?
Shenzhen GCL Electronics CO.,Ltd, founded in 1999 with the registered capital of 10 million dollars, has been a professional manufacturer of LED screen for more than 21 years. GCL is a high-tech enterprise which integrates researching, development,manufacturing, engineering, installation, sales and aftersales services. Headquartered in Shenzhen, China.GCL is staffed with over 300 employees and in our dust free workshop which covers more than 100,000 square feet, there are more than 30 high-speed production machines with high accuracy and more than 10 modern assembly lines. The annual capacity of GCL is over two hundred millions USD and it has been granted with more than ten LED application products-related patents and certifications in compliance with the ISO9001, ISO1400 and ISO18001 standards. Our products have also been certified with multiple standards, including EMC, CE, ROHS, CCC, FCC, ISO. GCL has finished more than 10,000 led screen and led lighting projects all over the world, including the international government projects in 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc.
uding module, power cable,signal cable, LED diod, IC, module mask, power supply, receiving card, etc.
