High Definition Outdoor LED Video Wall With 1/4 Scan Mode And 6mm Pixel Pitch
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Grock |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | Packing with Flight case & Wooden box & Hard paper box |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Color: | Full Color |
|---|---|---|---|
| Panel Size: | 256*128mm | Supplier Type: | ODM, OEM |
| Media Available: | Other | Use: | Advertising Publish |
| Function: | SDK | Specification: | Digital Poster, Video Wall |
| LED Chip: | Nationstar | Cabinet Size: | Customize |
| Brightness: | 6500nits | Scan Mode: | 1/4scan |
| Usage: | Advertising | Refresh Rate: | 1920Hz-3840Hz |
| Viewing Angle: | H120 V120 | Cabinet Material: | Iron |
| Certificate: | CE ROHS FCC | Input Voltage: | AC100~240V 50 /60 HZ |
| Pixel Pitch: | 6mm, P3.91 P4 P6 P8 P10 | Port: | Shenzhen |
| Highlight: | High Definition Outdoor LED Video Wall,6mm Pixel Pitch Outdoor LED Video Wall,High Definition LED Advertising Screen |
||
Product Description
|
Product
|
P2.5
|
P3
|
P3.81
|
P4
|
|||
|
Pitch(mm)
|
2.5
|
3
|
3.81
|
4
|
|||
|
Density(pixels/m2)
|
160000
|
111111
|
68798
|
62500
|
|||
|
LED Type
|
SMD1415
|
SMD1921
|
|
|
|||
|
Brightness(nits)
|
5000
|
5500
|
5500
|
5500
|
|||
|
Scan Method
|
1/16
|
1/16
|
1/16
|
1/8
|
|||
|
Cabinet Size(mm)
|
Customized
|
|
|
|
|||
|
Cabinet Material
|
Steel
|
|
|
|
|||
|
Cabinet Weight
|
45kg/m2
|
|
|
|
|||
|
Protection Level
|
IP65
|
|
|
|
|||
|
Cabinet Maintenance
|
Front Opening Service
|
|
|
|
|||
|
Max Power Consumption
|
800w/m2
|
720w/m2
|
800w/m2
|
|
|||
|
Average Power Consumption
|
270w/m2
|
240w/m2
|
270w/m2
|
|
|||
|
Refresh Rate
|
2880-3840HZ
|
|
|
|
|||
|
Grey Scale
|
16 bit
|
|
|
|
|||
|
Viewing Angle
|
H160o,V140o
|
|
|
|
|||
|
Voltage
|
AC100~240V(50-63Hz)
|
|
|
|
|||
|
Working Temperature
|
-30 oC - + 65 oC
|
|
|
|
|||
|
Working Humidity
|
10% -- 90%RH
|
|
|
|
|||
|
Color Temperature
|
6500-9500K
|
|
|
|
|||
|
Certificationa
|
EMC/CE/ROHS/CCC/FCC/ISO
|
|
|
|
|||
|
Certificationa
|
CE/ROHS/CCC/FCC/ISO
|
|
|
|
|||
