Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing

Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing

Product Details:

Place of Origin: Guangdong, China
Brand Name: GCL
Certification: EMC/CE/ROHS/CCC/FCC/BIS
Model Number: Gpro

Payment & Shipping Terms:

Minimum Order Quantity: Min. order: 20
Price: Price to be discussed
Get Best Price Contact Now

Detail Information

Application: Outdoor Type: LED
Color: Full Color Panel Size: 640X960MM, 640X960MM
Supplier Type: Original Manufacturer, ODM, OEM Media Available: Photo, EDA/CAD Models
Use: Advertising Publish, Retail Store, Welcome Display, Self-service Business, Airport, Restaurant & Hotel Supplies Function: SDK
Pixel Pitch: 8mm, 8mm, 8mm Specification: Video Wall
Touch Screen Type: Capacitive Brightness: 6000-10000nits, 6000-10000nits, 5500nits
Contrast Ratio: 2000:1, 2000:1 Lifespan (hours): 100000H, 100000H
IP Rating: IP65, IP65 HS Code: 8528591090
View Angle(H/V): 120/120, 120/120 Density: 15625
LED Type: SMD3535 Scan Method: 1/5
Module Size: 320*320mm Cabinet Material: Diecasting Aluminum
Cabinet Service: Front And Rear Service Refresh Rate: 1920-3840hz
Viewing Angle: H160 / V140
Highlight:

Commercial Outdoor Fixed LED Display

,

Seamless Splicing Outdoor Fixed LED Display

,

Seamless Splicing Outdoor LED Display Board

Product Description



Products Description;

Product P4 P8 P10 P10D
Pitch 4mm 8mm 10mm 10mm
Density(pixels/m²) 62500 15625 10000 10000
LED Type SMD1921 SMD2727 SMD2727 DIP346
Brightness 6000nits 7000nits 7000nits 8000nits
Scan Method 1/10 1/4 1/2 1/4
Panel Size 640×960mm
Module Size 320×320mm
Panel Material Die-casting Aluminum
Panel Weight 23.5Kg 19Kg 19Kg 21Kg
Protection Level IP65
Maintenance Front/Rear Service
Max Power Consumption 720W/㎡ 720W/㎡ 720W/㎡ 350W/㎡
Average Power Consumption 240W/㎡ 240W/㎡ 240W/㎡ 110W/㎡
Refresh Rate 3840Hz
Grey Scale 13-16bit
Viewing Angle H160°,V140° H100°,V50°
Voltage AC100~240V(50-60Hz)
Working Temperature -30℃ to 60℃
Working Humidity 10%-90%RH
Color Temperature 3000-9500K
Certifications CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO

Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing 0
Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing 1Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing 2Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing 3


ABOUT GCL
Shenzhen GCL Electronics CO., Ltd, founded in 1999, is a professional LED display manufacturer which integrates research, development, manufacturing, engineering, installing, sales and aftersales service. Headquartered in Shenzhen, China, GCL is staffed with over 300 employees and in our dust free workshop which covers more than 100,000 square feet, there are more than 40 high-speed production machines with high accuracy and more than 10 modern assembly lines. GCL has a very powerful productivity with over 5000 square meters LED screens each month. We have been granted with more than ten LED application products-related patents and certifications in compliance with the ISO 9001, ISO 1400 and ISO18001 standards. Our products have also been certificated with multiple standards, including CCC, FCC, CE, ROHS, UL, EMC, and ETL. GCL has finished more than 10,000 led screen projects all over the world, including some magnificent international government projects such as 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc. We have warehouses in America, Russia and Malaysia.
Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing 4
1999
GCL was registered and founded in Shenzhen, China.

2006
Overseas Department of GCL was founded, and GCL settled the first order overseas, 80sqm of outdoor P24 in Russia.

2007
GCL was awarded the design patent certificate of Utility Model for outdoor display listed. 2010 GCL was the LED screen supplier ofShanghai EXPO.

2011
GCL moved from Bao’an district to Longgang district for expanding the production.

2012
GCL became a member of China Optoelectronics Industry Association.

2014
GCL developed partnership cooperation in Russia, Sweden and the USA.

2015
GCL was the LED screen supplier for Milan EXPO 2015.

2016
GCL set up after-sales service center in Europe and the US.

2017
GCL set up the warehouse in Malaysia.

2018
GCL set up the warehouse and office in Texas, the US.

2019
GCL set up the warehouse and office in Moscow, Russia.
Commercial P8 HD TV Big Outdoor Fixed LED Display Outdoor LED Panel Seamless Splicing 5
