320x160mm Size Wall Mounted Fixed LED Display P10 For Commercial Advertising
Product Details:
Place of Origin: | Guangdong, China |
Brand Name: | GCL |
Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
Model Number: | Grock |
Payment & Shipping Terms:
Minimum Order Quantity: | Min. order: 20 |
---|---|
Price: | Price to be discussed |
Packaging Details: | Packing with Flight case & Wooden box & Hard paper box |
Supply Ability: | 5000 Square Meter/Square Meters per Month |
Detail Information |
|||
Application: | Outdoor Fixed Installation | Color: | Black |
---|---|---|---|
Panel Size: | Customized | Module Size: | 320x160mm |
LED Type: | SMD3535 | Cabinet Maintenance: | Rear Service |
Protection Level: | IP65 | LED Chip: | Epistar |
Weight: | 45kg/sqm | Pixel Pitch: | 10mm |
Port: | Shenzhen | ||
Highlight: | Wall Mounted Fixed LED Display,Commercial Advertising Fixed LED Display,Wall Mounted Outdoor Digital Display Board |
Product Description
Product Description
Specification
Product
|
Grock_P10
|
Pixel Pitch
|
10mm
|
LED Type
|
SMD3535
|
Brightness
|
5500nits
|
Scan Method
|
1/3
|
Cabinet Size
|
Customized
|
Module Size
|
320*160mm
|
Cabinet Material
|
Die-casting Aluminum
|
Cabinet Weight
|
45kg/sqm
|
Protection Level
|
IP65
|
Cabinet Maintenance
|
Rear Service
|
Max Power Consumption
|
800w/sqm
|
Ave Power Consumption
|
270w/sqm
|
Refresh Rate
|
1920-3840HZ
|
Grey Scale
|
16bit
|
Viewing Angle
|
H160 / V140
|
Voltage
|
AC100-240V(50-63HZ)
|
Working Temperature
|
-30℃ - +65℃
|
Working Humidity
|
10%-90% RH
|
Color Temperature
|
6500-9500K
|
Certifications
|
EMC/CE/ROHS/CCC/FCC/ISO
|
Popular Products
Click the next picture to learn GCL popular products.
Company Information
ABOUT GCL
Shenzhen GCL Electronics CO., Ltd, founded in 1999, is a professional LED display manufacturer which integrates research, development, manufacturing, engineering, installing, sales and aftersales service. Headquartered in Shenzhen, China, GCL is staffed with over 300 employees and in our dust free workshop which covers more than 100,000 square feet, there are more than 40 high-speed production machines with high accuracy and more than 10 modern assembly lines. GCL has a very powerful productivity with over 5000 square meters LED screens each month. We have been granted with more than ten LED application products-related patents and certifications in compliance with the ISO 9001, ISO 1400 and ISO18001 standards. Our products have also been certificated with multiple standards, including CCC, FCC, CE, ROHS, UL, EMC, and ETL. GCL has finished more than 10,000 led screen projects all over the world, including some magnificent international government projects such as 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc. We have warehouses in America, Russia and Malaysia.
1999
GCL was registered and founded in Shenzhen, China.
2006
2011
GCL was registered and founded in Shenzhen, China.
2006
Overseas Department of GCL was founded, and GCL settled the first order overseas, 80sqm of outdoor P24 in Russia.
2007
GCL was awarded the design patent certificate of Utility Model for outdoor display listed. 2010 GCL was the LED screen supplier ofShanghai EXPO.
2011
GCL moved from Bao’an district to Longgang district for expanding the production.
2012
GCL became a member of China Optoelectronics Industry Association.
2014
GCL developed partnership cooperation in Russia, Sweden and the USA.
2015
GCL was the LED screen supplier for Milan EXPO 2015.
2016
GCL set up after-sales service center in Europe and the US.
2017
GCL set up the warehouse in Malaysia.
2018
GCL set up the warehouse and office in Texas, the US.
2019
GCL set up the warehouse and office in Moscow, Russia.
Overseas Exhibitions
Showcases
FAQ
Q1. Is GCL a manufacturer or a trading company? Manufacturer. GCL has been a professional LED screen manufacturer for more than 21 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees. Q2. Why is the Alibaba account of your company only one year old? We have two Alibaba accounts, both under the same company name. The first one is 11 years old. To boost our sales, we registered a new Alibaba account in 2020. Q3. I have never cooperated with your company before, nor have I visited your factory, how do I know that your company is trustworthy? GCL was founded in 1999, we are the most experienced LED display factory in China. All of our company information displayed on Alibaba, including our company video, has been verified by Alibaba. The fact that we have done a lot of magnificent government projects all over the world proves that we are a very professional company. The fact that we provide 3 years warranty while all the other companies provide only 2 years proves that we are more confident about our product quality. You can do the purchase and transfer the money through Trade Assurance on Alibaba, which would 100% project you from any fraud.
Q4. How long is the warranty? The standard warranty is 3 years. It could be longer upon request. During the warranty, we would send the engineer team to the customer’s country for the maintenance of our products for free twice per year. Q5.What is your payment terms? Standard payment terms:30% T/T deposit, 70% T/T before shipment. Other payments terms could also be acceptable upon negotiation; Q6. What is the delivery time? Usually 12-15 working days after payment of deposit. Less than a week for our best sales products because we always keep about 500 square meters in stock. Q7. What technical supports can GCL offer? We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q8: What controlling system do you use ? Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc. Q9. Do you provide any free spare parts in each order? Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable, signal cable, LED diod , IC, module mask, power supply, receiving card, etc.
