Power Saving Advertising LED Display Screen Flexible Curtain P10 LED Display
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | P15.6 mesh led screen |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | plywood,flight case,paper board |
| Supply Ability: | 2000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Type: | LED |
|---|---|---|---|
| Color: | Black, Silver, White | Panel Size: | 500*1000mm |
| LED Chip: | DIP346 | Module Size: | 250*500mm |
| Brightness: | 8500nits | Refresh Rate: | 1920Hz-3840Hz |
| Life Span: | 10000hours | Viewing Angle: | 120/120 Degree |
| Warranty: | 3 Years | Material: | Waterproof Diecasting Cabinet |
| IP Rate: | IP65/IP65 | Voltage: | 110-240V/50-60HZ |
| Pixel Pitch: | 15.6 | Port: | Yantian(Shenzhen) Shekou(Shenzhen) |
| Highlight: | Power Saving Advertising LED Display Screen,Flexible Advertising LED Display Screen,Curtain LED Billboard Sign |
||
Product Description
IP65/IP65 Silver P10 P15.6 Transparent Flexible Curtain Digital Signage and Displays
Gmesh Product Introduction:
High Light Transmittance
Light transmittance:20%-60%
Low wind resistance
Great heat dissipation
Light and Slim
Cabinet weight: 9.5kg(P10 SND)
11kg(P15.6 DIP)
Cabinet Thickness:45mm
Front &Rear Maintenance
All parts be dismounted from the front;
Both front and rear maintenance;
Easy Maintenance
Loose 8 screws to dismount each module
Loose 8 screws to dismount the front cover,
then dismount the power supply, receiving card and HUB card
Seamless 90°Splicing
Optional Curve Lock
Concave and convex curve;
Curve degree:-15° to+15°
Integrated Power and Signal Cable
Save 50% of the cable connecting time
Parameters of Gmesh Series:
| Product | P10 | P16-A | P16-B | P16-C | P25 | P31.25 |
| Pitch | 10.4mm | 15.625mm | 15.625mm | 15.625-31.25mm | 25-31.25mm | 31.25mm |
| Density(pixels/m²) | 9216 | 4096 | 4096 | 2048 | 1280 | 1024 |
| LED Type | SMD2727 | SMD3535 | DIP346 | DIP346 | DIP346 | DIP346 |
| Brightness | 5500nits | 6000nits | 10000nits | 10000nits | 10000nits | 10000nits |
| Scan Method | 1/3 | Static | Static | Static | Static | Static |
| Panel Size | 500×1000mm | |||||
| Module Size | 250×500mm | |||||
| Panel Material | Die-casting Aluminum | |||||
| Panel Weight | 9kg | 9kg | 10.5kg | 10.5kg | 10.5kg | 10.5kg |
| Protection Level | IP65 | |||||
| Maintenance | Front&Rear Service | |||||
| Max Power Consumption | 680W/㎡ | 680W/㎡ | 350W/㎡ | 350W/㎡ | 350W/㎡ | 350W/㎡ |
| Average Power Consumption | 220W/㎡ | 220W/㎡ | 110W/㎡ | 110W/㎡ | 110W/㎡ | 110W/㎡ |
| Refresh Rate | 3840Hz | |||||
| Grey Scale | 16bit | |||||
| Viewing Angle | H140°,V120° | H140°,V120° | H100°,V50° | H100°,V50° | H100°,V50° | H100°,V50° |
| Voltage | AC100~240V(50-60Hz) | |||||
