High Tech Professional Outdoor Advertising Screen Display For Shopping Mall P8 LED Display
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gsurface |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | To protect the LED screen well during the long transportation :<br>1) If it's for rental use, we will pack all cabinets by flight cases;<br>2) If it's for fixed installation, we will pack all cabinets by plywood cases. |
| Supply Ability: | 10000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Video Play | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | Customized |
| Pixels: | 8mm | Module Size: | 320*320mm |
| Warranty: | 3years | Brightness: | 5500nits |
| Life Span: | 100000hours | Cabinet Size: | Customized |
| Scan Mode: | 1/5 | Refresh Rate: | 1920 -3840 Hz |
| Pixel Pitch: | 8mm | Port: | SHENZHEN |
| Highlight: | Professional Outdoor Advertising Screen Display,High Tech Outdoor Advertising Screen Display,High Tech Outdoor Advertising Screen |
||
Product Description
Look more Product
Products Description
Outdoor advertising sign board P6 P8 P10 full front service led board display screen Iron steel cabinet
| Model | Gsurface10 | Gsurface8 | Gsurface5.95 |
| Pixel Pitch (mm) | 10 | 8 | 5.95 |
| Pixel Density (dot/m2) | 10000 | 15625 | 28476 |
| LED Type | SMD3535 | SMD3535 | SMD2727 |
| Scanning | 3S | 5S | 9S |
| Module Size (mm) | 320*320 | 320*320 | 320*320 |
| Cabinet Size (mm) | Customized | ||
| Cabinet Weight (±0.25Kg) | 40kg/㎡ | ||
| Cabinet Resolution (PX* PX) | Customized | ||
| Cabinet Material | Steel (or Aluminum) | ||
| Brightness (CD/m2) | 6500 | ||
| Maximum Power Consumption (w/sqm) | 720 | ||
| Average Power Consumption (w/sqm) | 240 | ||
| Horizontal Viewing Angle (Deg) | 140° | ||
| Vertical Viewing Angle (Deg) | 140° | ||
| Grey Scale(bit) | 16 | ||
| Refresh Rate (Hz) | 1920-3840Hz | ||
| Input Voltage (V) | 110-240V | ||
| Input Frequency (Hz) | 60 | ||
| Storage Temperature (℃) | ﹣40℃－﹢80℃ | ||
| Working Temperature(℃) | ﹣20℃－﹢65℃ | ||
| Working Humidity (RH) | 95% | ||
| Cabinet Curve | Outward&Inward | ||
| Waterproof Level | IP65 | ||
| Working Environment | Outdoor | ||
| Installation Type | Fixed installation | ||
Company Profile
Shenzhen GCL Electronics CO.,Ltd, founded in 1999 with the registered capital of 10 million dollars, has been a professional manufacturer of LED screen for more than 21 years. GCL is a high-tech enterprise which integrates researching, development,manufacturing, engineering, installation, sales and aftersales services. Headquartered in Shenzhen, China.GCL is staffed with over 300 employees and in our dust free workshop which covers more than 100,000 square feet, there are more than 30 high-speed production machines with high accuracy and more than 10 modern assembly lines.
The annual capacity of GCL is over two hundred millions USD and it has been granted with more than ten LED application products-related patents and certifications in compliance with the ISO9001, ISO1400 and ISO18001 standards. Our products have also been certified with multiple standards, including CCC, FCC, CE, ROHS, EMC, and ETL.
GCL has finished more than 10,000 led screen and led lighting projects all over the world, including the international government projects in 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc.
The annual capacity of GCL is over two hundred millions USD and it has been granted with more than ten LED application products-related patents and certifications in compliance with the ISO9001, ISO1400 and ISO18001 standards. Our products have also been certified with multiple standards, including CCC, FCC, CE, ROHS, EMC, and ETL.
GCL has finished more than 10,000 led screen and led lighting projects all over the world, including the international government projects in 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc.
Want to Know more details about this product
