Customizable Indoor LED Display Screen Seamless Splicing P2.5 LED Display
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gspark |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | Flight case, Ply-wooden case |
| Supply Ability: | 5000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Conference Room | Type: | LED |
|---|---|---|---|
| Color: | Full Color | Panel Size: | 640*480mm |
| Brightness: | 700cd/sqm | Module Size: | 320*160mm |
| Refresh Rate: | 3840Hz | LED Chip: | SMD1515 |
| Viewing Angle: | 160H/160V | Scan Mode: | 1/20Scan |
| Cabinet Material: | Die-casting Alumium | Weight: | 7.5Kg/panel |
| IP Rate: | IP43/IP43 | Pixel Pitch: | P1.86 |
| Port: | Shenzhen China | Maintenance: | Front & Rear Service |
| Highlight: | Seamless Splicing Indoor LED Display Screen,Customizable Indoor LED Display Screen,Customizable Advertising LED Display Screen |
||
Product Description
Products Description
Indoor HD P2.5 led display screen video wall for Church, Meeting Room
Application
| Product | P1.5 | P1.86 | P2 | P2.5 |
| Pitch | 1.538mm | 1.86mm | 2mm | 2.5mm |
| Density(pixels/m²) | 422500 | 288906 | 250000 | 160000 |
| LED Type | SMD1212 | SMD1515 | SMD1515 | SMD2020 |
| Brightness | 600nits | 700nits | 700nits | 700nits |
| Scan Method | 1/52 | 1/43 | 1/40 | 1/32 |
| Panel Size | 640×480mm | |||
| Module Size | 320×160mm | |||
| Panel Material | Die-casting Aluminum | |||
| Panel Weight | 7 kg | |||
| Protection Level | IP31 | |||
| Maintenance | Full Front Service | |||
| Max Power Consumption | 450W/㎡ | 450W/㎡ | 450W/㎡ | 450W/㎡ |
| Average Power Consumption | 150W/㎡ | 150W/㎡ | 150W/㎡ | 150W/㎡ |
| Refresh Rate | 3840Hz | |||
| Grey Scale | 13~16bit | |||
| Viewing Angle | H160°,V160° | |||
| Voltage | AC100~240V(50-60Hz) | |||
| Working Temperature | -20℃to 60℃ | |||
| Working Humidity | 10%-90%RH | |||
| Color Temperature | 3000-9500K | |||
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO | |||
Want to Know more details about this product
