Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
Product Details:
| Place of Origin: | China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gpro P2.5/P3.07/P4/P5.92/P8/P10(DIP)/P16（DIP) |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | Single package size:120X980X50 cm |
| Delivery Time: | 15-22Days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 2000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Highlight: | Customizable Outdoor Advertising LED Display,Fixed Installation Outdoor Advertising LED Display,Fixed Installation Outdoor LED Billboard |
||
|---|---|---|---|
Product Description
Double Waterproof Design
both cabinet and module are waterproof
Convenient Maintenance
100%Front Maintenance
Rear Maintenance
47% Lighter
18kg/cabinet
Traditional cabinet :45-55kg/㎡
High-end Design
Diecasting Aluminum Cabinet
High-end Module
Fan-less,Noiseless
IP65
Born For All Weathers
Energy-saying
SMD: Save 30%；DIP: Save 50%
Right angle&arc stitching
Supports straight edge splicing, arc splicing, and 90 ° right angle splicing
Modular design, ultra strong protection
| Product | P5.9 | P8 | P10 | P10D | P16 |
| Pitch | 5.92mm | 8mm | 10mm | 10mm | 16mm |
| Density(pixels/m²) | 28476 | 15625 | 10000 | 10000 | 3906 |
| LED Type | SMD2727 | SMD2727 | SMD2727 | DIP346 | DIP346 |
| Brightness | 7000nits | 7000nits | 7000nits | 8000nits | 8000nits |
| Scan Method | 1/6 | 1/4 | 1/2 | 1/4 | 静态 |
| Panel Size | 640×960mm | ||||
| Module Size | 320×320mm | ||||
| Panel Material | Die-casting Aluminum | ||||
| Panel Weight | 19Kg | 19Kg | 19Kg | 21Kg | 21Kg |
| Protection Level | IP65 | ||||
| Maintenance | Front/Rear Service | ||||
| Max Power Consumption | 720W/㎡ | 720W/㎡ | 720W/㎡ | 350W/㎡ | 350W/㎡ |
| Average Power Consumption | 240W/㎡ | 240W/㎡ | 240W/㎡ | 110W/㎡ | 110W/㎡ |
| Refresh Rate | 3840Hz | ||||
| Grey Scale | 13-16bit | ||||
| Viewing Angle | H160°,V140° | H100°,V50° | |||
| Voltage | AC100~240V(50-60Hz) | ||||
| Working Temperature | -30℃ to 60℃ | ||||
| Working Humidity | 10%-90%RH | ||||
| Color Temperature | 3000-9500K | ||||
| Certifications | CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO | ||||
