GCL P3.9 Full Color Waterproof Outdoor LED Display Board For Shopping Mall
Product Details:
| Place of Origin: | Guangdong, China |
| Brand Name: | GCL |
| Certification: | EMC/CE/ROHS/CCC/FCC/BIS |
| Model Number: | Gsurface |
Payment & Shipping Terms:
| Minimum Order Quantity: | Min. order: 20 |
|---|---|
| Price: | Price to be discussed |
| Packaging Details: | plywood,flight case,paper board |
| Supply Ability: | 2000 Square Meter/Square Meters per Month |
|
Detail Information |
|||
| Application: | Outdoor | Type: | LED |
|---|---|---|---|
| Color: | FULL COLOR | Panel Size: | H39.4"xW39.4", H39.4"xW39.4" |
| Supplier Type: | Original Manufacturer, ODM, OEM | Media Available: | Photo, Other, Video |
| Use: | Advertising Publish, Retail Store, Shopping Mall, Display Of Dishes, Welcome Display, Self-service Business, Exhibition Hall, Wayfinding, Subway, Elevator, Restaurant & Hotel Supplies, Large Commercial Building, Advertisement Billboard, Large Sports Center | Pixel Pitch: | 3.9mm, 3.9mm |
| Specification: | Digital Poster, Video Wall | Touch Screen Type: | Capacitive |
| Brightness: | 6000nits, 6000nits, 6000nits | Pixel Density: | 65536, 65536 |
| Lifespan (hours): | 10,000, 10,000 | IP Rating: | IP65, IP65 |
| HS Code: | / | Resolution: | 2K-4K |
| View Angle（H/V）: | H160°/V160°, H160°/V160° | Module Size: | H9.8"xW9.8" |
| Cabinet Material: | Profile Aluminum | Scan Method: | 1/8 |
| Module Weight: | 66Ib | LED Type: | SMD1921 |
| Protection Level: | IP65 | Cabinet Maintenance: | Front Service |
| Refresh Rate: | 3840HZ | Viewing Angle: | H160°,V160° |
| Port: | Shenzhen | ||
| Highlight: | Full Color Outdoor LED Display Board,Waterproof Outdoor LED Display Board,Shopping Mall Facade LED Screen |
||
Product Description
P3.9 P4.8P5.2 Outdoor Full Color Waterproof LED Video Wall for Shopping Mall Advertising
Products Description:
Parameters of Gsurface-II:
| Name | P3.91 | P4.81 | P5.2 |
| Module | |||
| LED Type | SMD1921 | SMD1921 | SMD1921 |
| Pixel Pitch(mm) | 3.90625 | 4.8077 | 5.208 |
| Module Resolution | 64*64 | 52*52 | 48*48 |
| Module Size(mm) | 250*250 | 250*250 | 250*250 |
| Scan Method | 1/16s;1/8s | 1/7s | 1/8s |
| Cabinet | |||
| Module Quantity | 4*4 | 4*4 | 4*4 |
| Cabinet Resolution | 256*256 | 208*208 | 192*192 |
| Cabinet Size(mm) | 1000*1000*100;Customizable | ||
| Cabinet Area(㎡) | 1 | ||
| Cabinet Material | Profile Aluminum | ||
| Density(pixels/㎡) | 65536 | 43264 | 36864 |
| Protection Level | IP65 | ||
| Optics | |||
| Brightness(nits) | 5500; 6500 | 5500 | 5500 |
| Calibration | Support Single-dot Calibration | ||
| Color Temperature | 1700-9500K Adjustable | ||
| Viewing Angle | H140°,V140° | ||
| Light Decay Rate | <3% | ||
| Contrast Ratio | 9000:01:00 | ||
| Grey Scale | 13-16bit | ||
| Electric | |||
| Max Power Consumption/㎡ | 680W; 880W | 640W | 640W |
| Average Power Consumption/㎡ | 230W; 290W | 210W | 210W |
| Cabinet Maintenance | Front Service | ||
| Input Voltage | AC100~240V(50-60Hz) | ||
Exhibition
Company Profile
Shenzhen GCL Electronics CO.,Ltd, founded in 1999 with the registered capital of 10 million dollars, has been a professional manufacturer of LED screen for more than 21 years. GCL is a high-tech enterprise which integrates researching, development,manufacturing, engineering, installation, sales and aftersales services. Headquartered in Shenzhen, China.GCL is staffed with over 300 employees and in our dust free workshop which covers more than 100,000 square feet, there are more than 30 high-speed production machines with high accuracy and more than 10 modern assembly lines.
The annual capacity of GCL is over two hundred millions USD and it has been granted with more than ten LED application products-related patents and certifications in compliance with the ISO9001, ISO1400 and ISO18001 standards. Our products have also been certified with multiple standards, including EMC, CE, ROHS, CCC, FCC, ISO.
GCL has finished more than 10,000 led screen and led lighting projects all over the world, including the international government projects in 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc.
The annual capacity of GCL is over two hundred millions USD and it has been granted with more than ten LED application products-related patents and certifications in compliance with the ISO9001, ISO1400 and ISO18001 standards. Our products have also been certified with multiple standards, including EMC, CE, ROHS, CCC, FCC, ISO.
GCL has finished more than 10,000 led screen and led lighting projects all over the world, including the international government projects in 2010 World Cup in South Africa, 2010 Shanghai Expo, 2014 China-Asian Expo, 2015 Milan Expo, etc.
Advantages
1.GCL has been a professional led display suppier since 1999.
2.Provide 3 years or more warranty but 95% supplier provide only 2 years.
3. Free technique training and can send engineer to your country to help with the led project if requested.
4.GCL based in shenzhen but we have warehouse and office in Dallas, The united states,and Russia.
To protect the LED screen well during the long transportation :
1) If it's for rental use, we will pack all cabinets by flight cases;
2) If it's for fixed installation, we will pack all cabinets by plywood cases .
1) If it's for rental use, we will pack all cabinets by flight cases;
2) If it's for fixed installation, we will pack all cabinets by plywood cases .
Q1. Is GCL a manufacturer or a trading company?
Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty?
The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms?
Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time?
Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer?
We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q6: What controlling system do you use ?
Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order?
Manufacturer. GCL has been a professional LED screen manufacturer for more than 19 years, since 1999. Our factory covers more than 100,000 square feet and we are staffed with about 300 employees.
Q2. How long is the warranty?
The standard warranty is 3 years. It could be longer upon request.
Q3.What is your payment terms?
Payment terms:30% T/T deposit, 70% T/T before shipment.
Q4. What is the delivery time?
Usually 12-15 working days after payment of deposit. Less than a week for our best sales because we always keep about 500 square meters in stock.
Q5. What technical supports can GCL offer?
We provide all kinds of technology trainings for free, including the operation and maintenance training of the LED screens in our factory. All operation manuals, software, test reports , CAD drawings of the steel structure and instruction of installing the cabinets and connecting the signal/power cables can be provided for free. If required, GCL can send an engineer team to the country of the customer to instruct the installation.
Q6: What controlling system do you use ?
Our standard controlling system is Novastar which is the most famous and popular system in the market. We can also provide other control systems such as Colorlight, Linsn, Xixun, Onbon, etc.
Q7. Do you provide any free spare parts in each order?
Yes, a certain amount of spare parts will be provided for free, spare parts including module, power cable,signal cable, LED diod, IC, module mask, power supply, receiving card, etc.
