Product Details:
|
| Product: | Transparent P3.91 Mm LED Display | Brightness: | Over 5000nits |
|---|---|---|---|
| Warranty: | 2 Years | Application: | Indoor |
| Technology: | Frontage-lighting | Screen Dimension: | Customized |
| Material: | Acrylic Frame Rental Led Wall | ||
| High Light: | P3.91 Outdoor Advertising LED Screen,NTSC Outdoor Advertising LED Screen,SECAM Rental Stage Led Display |
||
500x1000 P3.91 Outdoor Advertising Waterproof LED Screens rental stage led display
Technical Parameters
| Pitch Size | 3.91mm |
| Module Size | 250*250mm |
| Module Pixel(dots) | 64dots*64dots |
| Pixel Configuration | 1 Red, 1 Green, 1 Blue SMD 3-in-1 |
| LED chip | Sanan |
| Color scale | 65536degree/16777216colors |
| Pixel density | 64510pixels/square meter |
| View angle(H/V) | ≥140/140degree |
| Brightness | ≥6000cd/square meter |
| Brightness adjustment | 64 level automatic or manual |
| View distance | 3--200m |
| Power consumption | 100-1200W/square meter |
| Net weight | 30kg/square meter |
| Operating temperature | —25°C~+60°C |
| Operating humidity | 10%—95%RH |
| Life time | ≥100,000hours |
| Out of control dot | ≤1/10,000 |
| Whole Display Flatness | ≤1mm Juncture |
| Exchange frame speed | >150frames per second |
| Refresh frame frequency | 1920Hz-3840Hz |
| Control distance | 120m (without repeater), single mode fiber:20km, multi mode fiber: 500m |
| Power | 110V/220V±15% 50/60Hz |
| Operating system | Windows series |
| Drive mode | constant current driving, 1/13 scan |
| Display mode | VGA640X480—VGA1600X1024 |
| Protection Level | IP65 |
| Maintenance way | Rear access |
| Accepting signal | PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI |
Connection System Diagram:
