Product Details:
|
| Product Name: | Indoor P4 Digital Advertising LED Display Screen Full Color SMD 2121 | Pixel: | 62500 Dots/㎡ |
|---|---|---|---|
| Module Size(W*H): | 256x 128 Mm | Refresh Rate:: | ≥1920 Hz |
| Brightness: | 1000 Nits | Usage: | Indoor |
| High Light: | P4mm Indoor Advertising LED Display Screen,256x128mm Indoor Advertising LED Display Screen,SMD2121 Electronic Advertising Display Screen |
||
Indoor P4 Digital Advertising LED Display Screen Full Color SMD 2121
| Pitch: | 4.81mm | Density: | 43222 Dot/㎡ |
|---|---|---|---|
| Module Size: | 250x250mm | Module Resolution: | 52x52 Dot |
| LED Standard: | SMD2121 | Brightness: | ≥1000 Cd/sqm |
| Viewing Distance: | 4.81-50m | Warranty Period: | 2 Years |
| High Light: |
indoor full color led display screen,indoor rental led display |
||
Product Description
Application
500*500/500*1000 rental series is one of the most mature rental led display in stage performance, bar entertainment, ceremonial wedding, conference, exhibition, musical theater, etc. industry, etc. it came along announced the successful application of Aluminum Diecasting technology in led display market. With features of weight, portable, easy to install & dismantle.Fanless design and good heat dissipation make rental events labor-saving, high efficiency and cost-effective.
Product feature
1. Seamless assembly
With CNC processing, the range of tolerance is controlled within 0.1mm that guarantees the seamless assembly and perfect performance is presented
2. Perfect Details Design
Chamfering designed cabinet corner protects the user from accidental damage.
3. Modularization design, Friendly Maintenance
Modularization design makes assembly and maintenance quickly and efficiently, and front and rear maintenance are available which is you're your choice.
4. Curve Installation compatible,creative design
Concave and convex radian design optional , helping your LED video wall creative and changeable.
5. Light weight and Ultra-thin
The weight of each cabinet is less that 7kg that makes it easy to carry and labor-saving, high efficiency and cost-effective.
Core technique solution of 500*500 Series
1. High Quality Driver IC
Chipone Series high quality Driver IC solution with Anti-ghost function help reducing your worry. And ≥ 1920Hz refresh rate enable us to do Live Broadcasting, lifelike animated picture and videos bring us an eye feast.
2. Low gray level adjustment effect
Light series with excellent gray level adjustment function ensuring your requirement on the brightness and color uniformity.
Specification
| ITEM NO:P4.81 | |
| LED Module Parameters | |
| Pixel Pitch | 4.81mm |
| Pixel Density | 43222dot/m2 |
| LED Configuration | 1R1G1B |
| LED Type | SMD2121 |
| Module resolution | 52*52dots |
| Module Size | 250*250 mm |
| LED Cabinet Parameters | |
| No of module | 2*2 |
| Cabinet Size | 500*500*75mm |
| Cabinet Weight | 6.8Kg |
| Flatness | gap<0.2mm |
| Maintain Way | optional |
| IP Rating | IP 65 |
| Cabinet Material | Aluminium die casting |
| General Parameters | |
| Driving method/Scan method | Constant current ;1/13 |
| Driving IC | 2038s |
| Gray Scale | 65536 |
| Refresh rate | ≥1920Hz |
| Luminance of white balance | ≥1000cd/m2 |
| Color temperature | 4500K-9500K |
| View angle | H:120°, V:120° |
| Uniformity of the luminance and chromaticity | ≥97% |
| Max.Power Consumption | 800W/m2 |
| Avg.Power Consumption | 360W/m2 |
| Input Voltage | AC220V/50Hz |
| Frame Rate | 60Hz |
| MTBF | 100000 Hours |
| Operating Temperature/Humidity | -20 - 60°C/ 10%-90%RH |
| Certification | FCC,CE,Rosh |
| Blind spot rate | ≤0.01% |
| Support Input | Composite, S-video, DVI,HDMI, SDI,HD-SDI,VGA |
| Control Distance | Ethernet cable≤100m or Fiber Optic>100m |
FAQ
1. Can we make any size of led display?
Nope, according the led module size and cabient size, such as ph4.81mm is 500x500mm for smallest unit.
2. What's best size of led display?
The best aspect ratio of LED display are W16:H9 or W4:H3
3. How to install led display?
We will provide drawing of steel structure or hanging truss,then you can install led display very easy.
4. How to order LED display?
Please tell me indoor or outdoor do you need,size of led display,where will be application of led display.
5. How to shipment?
Normally, ph4.81mm will be shipped by air and dhl, becayse the value is high than other product.
6. How to payment?
You can transfer payment by TT,west union, Alibaba Trade Assurance online.
